Tantalum Fasteners


When nickel, titanium or zirconium alloys are not enough...


Tantalum Fasteners for Extreme Corrosion


  • Immune to numerous acids and chemicals (corrosion tables)

  • Better corrosion resistance than nickel alloys, titanium or zirconium

  • High strength and stiffness in vacuum and inert gas up to 2000°C (3600°F)

  • Can become brittle when used in oxygen above 300°C

  • High purity and biocompatibilty

  • Physical Properties

  • Tantalum's Chemistry Grades & Specs

  • Datasheet for tantalum


Tantalum fasteners are best known for its unmatched corrosion resistance and chemical inertness. Tantalum fasteners have a similar corrosion resistance to that of glass, but all of the typical mechanical and electrical properties of a metal.

Tantalum fasteners are also extremely stable at high temperatures, since tantalum has a melting point around 3000°C. High temperature applications require vaccum or inert gas since tantalum may embrittle when used in oxygen rich environments above 250°C.  Tantalum fasteners are also one of the most bio-compatible metals available and is also radio-opaque due to its high density (16.68 g/cm3).

All tantalum fasteners are available in commercially pure tantalum and tantalum 2.5% tungsten (Ta-2.5%W).

Contact us to see if your required tantalum fasteners are in stock and how our engineers may help you with your tantalum fasteners application.

Resources: Tantalum Torque Spec

Tantalum Fastener Types: Bolts, Nuts, Screws, Threaded Rods, Washers




Tantalum Grades, Chemistry & Specifications

Tantalum (Commercially Pure)

Commercially pure tantalum metal 99.95% pure tantalum as a minimum and has the best corrosion resistant properties of any metal when it come to most acids. While its corrosion resistance is exceptional, it is relatively soft and mechanically similar in strength to copper.

Specifications: UNS R05200

   Tantalum (CP)TaNbWMoOTiNiFeNCSiH
Max%>99.950.1000.0500.0200.0150.0100.0100.0100.0100.0100.0100.010


Tantalum 2.5% Tungsten (Ta-2.5W)

This grade of tantalum alloyed with 2.5% tungsten provided better overall strength while maintaining its exception corrosion resistant properties. For tantalum fastener applications this is usually preferred.

Specifications: UNS R05252

 Tantalum 2.5%WTaWNbMoOTiNiFe NCSiH
Typical%Bal2.50.500.0200.0150.0100.0100.0100.0100.0100.0050.002




Physical Properties

  • Density 16.6 g/cc

  • Melting Point 3290 K, 2996°C, 5462°F

  • Boiling Point 5731 K, 6100°C, 9856°F

  • Coefficient of Thermal Expansion (20°C) 6.5 x 10(-6) / °C

  • Electrical Resistivity (20°C) 13.5 microhms-cm

  • Electrical Conductivity 13% IACS

  • Specific Heat .036 cal/g/°C

  • Thermal Conductivity .13 cal/cm(2)/cm°C/sec






Tantalum Tensile Data

TANTALUM - Tensile Data

Temperature(°F)Ultimate Tensile (ksi)Yield Strength at0.2% Offset (ksi)Elongation %
Room Temp.40.025.050.0
20029.022.0
40028.012.0
60028.08.0
80027.02.5


TANTALUM 2.5% W - Tensile Data

Temperature(°F)Ultimate Tensile (ksi)Yield Strength at0.2% Offset (ksi)Elongation %
Room Temp.50.035.025.0
20048.030.015.0
40042.027.410.0
48540.025.510.0


Tantalum Corrosion Resistance Table

TANTALUM SHOWS A NIL CORROSION RATE TO THE FOLLOWING MEDIAFor all temperatures up to at least 302°F (150°C) unless otherwise indicated
Acetic acid
Acetic anhydride
Acetone
Air,<300°C (570°F)
Alcohols
Aldehydes
Aluminum chloride
Aluminum nitrate
Aluminum sulfate
Amines
Ammonium bicarbonate
Ammonium carbonate
Ammonium chloride
Ammonium nitrate
Ammonium acid phosphate
Ammonium phosphate
Ammonium sulfate
Amyl acetate or chloride
Aniline hydrochloride
Aqua regia
Barium carbonate
Barium chloride
Barium hydroxide
Barium nitrate
Benzoic acid
Body fluids
Boric acid
Bromine, dry, <300°C (570°F)
Bromine, wet
Butyric acid
Calcium bicarbonate
Calcium bisulfates
Calcium bisulfites
Calcium carbonate
Calcium chloride
Calcium hydroxide
Calcium hypochlorite
Carbolic acid
Carbon dioxide
Chloric acid
Chlorinated brine
Chlorine, dry, <250°C (480°F)
Chlorine, wet, <350°C (662°F)
Chlorine oxides
Chloroacetic acid
Chromic acid
Chrome plating solutions
Citric acid
Cleaning solutions
Copper salts
Dichloroacetic acid
Dimethylformaldehyde
Ethylene dibromideEthyl sulfate
Fatty acids
Ferric chloride
Ferric sulfate
Ferrous sulfate
Food stuffs
Formaldehyde
Formic acid
Fruits
Glycerine
Graphite, <1000°C
Hydroiodic acid
Hydrobromic acid
Hydrocarbons
Hydrochloric acid
Hydrogen bromide, <400°C
Hydrogen chloride, <350°C
Hydrogen iodide
Hydrogen peroxide
Hydrogen sulfide
Hydroxyacetic acid
Hypochlorus acid
Iodine, <300°C (570°F)
Ketones
Lactic acid
Lead salts
Magnesium chloride
Magnesium hydroxide
Magnesium sulfate
Maleic acid
Manganous chloride
Methyl alcohol
Methylsulfuric acid
Milk
Mineral oils
Mixed acids (sulfuric-nitric)
Motor fuels
Nickel salts
Nitric acid
Nitric acid, fuming
Nitric oxides
Nitrogen, <300°C (570°F)
Nitrous acid
Nitrosyl chloride
Organic chlorides
Organic acids
Organic esters
Organic salts
Oxalic acid
Oxygen, <300°C (570°F)
Pechloric acid
Petroleum products
Phenol
Phosphoric acid, <4ppmF,<180°C
Phosphorus, <700°C (1290°F)
Phosphorus chlorides
Phosphorus oxychloride
Phthalic anhydride
Pickling acids, except HNO3-HF
Potassium bromide
Potassium chloride
Potassium dichromate
Potassium ferricyanide
Potassium iodine-iodine
Potassium nitrate
Potassium permanganate
Potassium sulfate
Potassium thiosulfate
Propionic acid
Refrigerants
Sea water
Silver nitrate
Sodium acetate
Sodium aluminate
Sodium bisulfate, solution
Sodium bromide
Sodium chlorate
Sodium chloride
Sodium citrate
Sodium cyanide
Sodium dichromate
Sodium hypochlorite
Sodium nitrate
Sodium nitrite
Sodium phosphate
Sodium silicate
Sodium sulfate
Sodium sulfide
Sodium sulfite
Sodium thiosulfate
Stearic acid
Succinic acid
Sugar
Sulfamic acid
Sulfur, <500°C (930°F)
Sulfur chlorides
Sulfur dioxide
Sulfuric acid, to 175°C (350°F)
Sulfurous acid
Sulfuryl chloride
Tannic acid
Tartaric acid
Thoinyl chloride
Tin salts
Zinc chloride
Zinc sulphate
TANTALUM SHOWS LIMITED CORROSION RESISTANCE TO THE FOLLOWING MEDIA
Air,>300°C (570°F)
Ammonia
Ammonium hydroxide
Fluoride salt
Hydrofluoric acid
Hydrogen, >300°C (570°F)Hydrogen fluoride
Oleum (fuming sulfuric acid)
Potassium carbonate
Potassium hydroxide, dilute
Potassium hydroxide, conc.
Potassium pyrosulfate, molten
Sodium bisulfate, molten
Sodium carbonate
Sodium hydroxide, dilute
Sodium hydroxide, conc.
Sodium pyrosulfate, molten
Sulfur trioxide
Sulfuric acid, >175°C (350°F)
